Refrigerant Line Arrangement for 2005 Mercedes-Benz CLK500
No.
Part # / Description / Price
Price
10
MSRP $474.00
$454.40
15
MSRP $95.00
$91.20
17
MSRP $3.50
$3.36
20
MSRP $167.00
$152.00
20
Refrigerant Drier For AC
Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Drying insert. At condenser. Air conditioner.
MSRP $340.00
$324.80
MSRP $340.00
$324.80
21
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: Heater. 7.5X2.0Strength / hardness class: EPDMInside diameter: 7,5mmOutside diameter: 11,5mmMaterial thickness: 2mm. HEATING. 7.5X2.0Strength / hardness class: EPDMInside diameter: 7,5mmOutside diameter: 11,5mmMaterial thickness: 2mm. MOUNTING PLATE TO DRI ...
MSRP $3.70
$3.52
MSRP $3.70
$3.52
22
Metal Mounting Sheet Mercedes-Benz
Mercedes-Benz Description: At dehydrator. Pressure lines to drier. Drier to condenser.
MSRP $8.00
$7.52
MSRP $8.00
$7.52
24
MSRP $12.00
$11.36
25
Pressure Sensor Mercedes-Benz
Mercedes-Benz Description: Refrigerant line. Reservoir. Sprinter van. Refrigerant condenser. Refrigerant pressure sensor. Roof. Metris. Rear. At condenser,bottom m10.
MSRP $159.00
$152.00
MSRP $159.00
$152.00
25
Temperature Sensor Mercedes-Benz
Mercedes-Benz Description: To condenser. On liquid reservoir. Refrigerant pressure and temperature sensor. Coolant temperatuter sensor.
MSRP $80.00
$76.80
MSRP $80.00
$76.80
30
MSRP $11.50
$10.80
40
MSRP $154.00
$147.20
50
O-Ring Mercedes-Benz
Mercedes-Benz Description: Sprinter van. Type 1. Refrigerant line to mounting plate. 9.5X2.6
Diameter: 9,5mm
Inside diameter: 9,5mm
Outside diameter: 14,7mm
Material thickness: 2,6mm. Engine Mounted A/C. 9.5 x 2.5mm. All Required. 9.5 x 2.6mm.
Diameter: 9,5mm
Inside diameter: 9,5mm
Outside diameter: 14,7mm
Material thickness: 2,6mm. Engine Mounted A/C. 9.5 x 2.5mm. All Required. 9.5 x 2.6mm.
MSRP $3.20
$3.01
MSRP $3.20
$3.01
65
Rear AC Line Guide Mercedes-Benz
Mercedes-Benz Description: Pipe line to condenser. Refrigerant line. At condenser. From condenser to liquid tank. Pressure line to condenser. Roof Mounted A/C. All Required. Center. Pipeline.
MSRP $6.25
$5.92
MSRP $6.25
$5.92
66
Valve Element Mercedes-Benz
Mercedes-Benz Description: Filling connection. Filler connection. High-pressure line. Filling valve. Suction line. Service connection, high pressure, air conditioning system. Valve element. To refrigerant line.
MSRP $19.50
$18.40
MSRP $19.50
$18.40
70
Grommet Mercedes-Benz
Mercedes-Benz Description: Suction line to bracket. At solenoid valve. Mounting solenoid valve. Solenoid valve to crossmember. At bracket on shock absorber console.
80
Snap Fastener Mercedes-Benz
Mercedes-Benz Description: Suction line to bracket. At bracket on shock absorber console.
120
MSRP $145.00
$139.20
130
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: Line to air conditioning system. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOutside diameter: 18mmMaterial thickness: 2mm. TUBING AT EXPANSION VALVE. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOut ...
140
MSRP $3.00
$2.88
150
Spacer Mercedes-Benz
Mercedes-Benz Description: Fuel line to side member. For fuel line to longitudinal member. Fuel lines to front partition panel.
160
Fastening Clamp Mercedes-Benz
Mercedes-Benz Description: Fuel lines to front partition panel. At floor.
MSRP $2.90
$2.72
MSRP $2.90
$2.72
180
180
300
MSRP $195.00
$187.20
300
MSRP $242.00
$232.00
310
A/C Line O-Ring Mercedes-Benz
Mercedes-Benz Description: AT CONDENSER. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. PRESSURE LINE TO EXPANSION VALVE. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. Refrigerant li ...
330
MSRP $258.00
$246.40
335
A/C Line O-Ring Mercedes-Benz
Mercedes-Benz Description: SUCTION LINE 13.7X2.5 MM. 13.7X2.5
Diameter: 18,7mm
Strength / hardness class: EPDM
Inside diameter: 13,7mm
Outside diameter: 18,7mm
Material thickness: 2,5mm.
Diameter: 18,7mm
Strength / hardness class: EPDM
Inside diameter: 13,7mm
Outside diameter: 18,7mm
Material thickness: 2,5mm.
MSRP $14.50
$13.87
MSRP $14.50
$13.87
340
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: Piping to refrigerant compressor. 23.8X2.4Diameter: 28,6mmStrength / hardness class: EPDMInside diameter: 23,8mmOutside diameter: 28,6mmMaterial thickness: 2,4mm. Refrigerant line. 23.8X2.4Diameter: 28,6mmStrength / hardness class: EPDMInside diameter: 23, ...
MSRP $3.60
$3.38
MSRP $3.60
$3.38
345
Valve Mercedes-Benz
Mercedes-Benz Description: Test connection. De-aeration valve. Filling valve. In suction line.
MSRP $29.50
$28.00
MSRP $29.50
$28.00
450
Cap Screw Mercedes-Benz
Mercedes-Benz Description: M8X30-10.9
Diameter: 8mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Steering coupling to steering shaft. Line to compressor. Stop buffer to frame. Plug connection, separation point.
Diameter: 8mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Steering coupling to steering shaft. Line to compressor. Stop buffer to frame. Plug connection, separation point.
MSRP $6.00
$5.60
MSRP $6.00
$5.60
450
Combination Bolt Mercedes-Benz
Mercedes-Benz Description: M8x30. Refrigerant line to compressor. Pressure line to compressor.
715
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: 4-PIN MQS
Model 1: MQS
Slots: 4
Release tool: W220 589 01 99 60.
Model 1: MQS
Slots: 4
Release tool: W220 589 01 99 60.
MSRP $5.75
$5.44
MSRP $5.75
$5.44
833
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $8.00
$7.52
MSRP $8.00
$7.52
