Refrigerant Line Arrangement for 2018 Mercedes-Benz AMG GT R
No.
Part # / Description / Price
Price
20
Sealing Ring
Mercedes-Benz
Mercedes-Benz Description: Heater. 7.5X2.0Strength / hardness class: EPDMInside diameter: 7,5mmOutside diameter: 11,5mmMaterial thickness: 2mm. HEATING. 7.5X2.0Strength / hardness class: EPDMInside diameter: 7,5mmOutside diameter: 11,5mmMaterial thickness: 2mm. MOUNTING PLATE TO DRI ...
MSRP $3.70
$3.52
MSRP $3.70
$3.52
20
O-Ring Mercedes-Benz
Mercedes-Benz Description: Sprinter van. Type 1. Refrigerant line to mounting plate. 9.5X2.6
Diameter: 9,5mm
Inside diameter: 9,5mm
Outside diameter: 14,7mm
Material thickness: 2,6mm. Engine Mounted A/C. 9.5 x 2.5mm. All Required. 9.5 x 2.6mm.
Diameter: 9,5mm
Inside diameter: 9,5mm
Outside diameter: 14,7mm
Material thickness: 2,6mm. Engine Mounted A/C. 9.5 x 2.5mm. All Required. 9.5 x 2.6mm.
MSRP $3.20
$3.01
MSRP $3.20
$3.01
30
A/C Line O-Ring Mercedes-Benz
Mercedes-Benz Description: SUCTION LINE 13.7X2.5 MM. 13.7X2.5
Diameter: 18,7mm
Strength / hardness class: EPDM
Inside diameter: 13,7mm
Outside diameter: 18,7mm
Material thickness: 2,5mm.
Diameter: 18,7mm
Strength / hardness class: EPDM
Inside diameter: 13,7mm
Outside diameter: 18,7mm
Material thickness: 2,5mm.
MSRP $14.50
$13.87
MSRP $14.50
$13.87
30
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: Line to air conditioning system. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOutside diameter: 18mmMaterial thickness: 2mm. TUBING AT EXPANSION VALVE. 14X2 MMDiameter: 18mmStrength / hardness class: EPDMInside diameter: 14mmOut ...
60
Refrigerant Line Mercedes-Benz
Mercedes-Benz Description: From compressor to separation point.
MSRP $294.00
$281.60
MSRP $294.00
$281.60
65
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: Piping to refrigerant compressor. 23.8X2.4Diameter: 28,6mmStrength / hardness class: EPDMInside diameter: 23,8mmOutside diameter: 28,6mmMaterial thickness: 2,4mm. Refrigerant line. 23.8X2.4Diameter: 28,6mmStrength / hardness class: EPDMInside diameter: 23, ...
MSRP $3.60
$3.38
MSRP $3.60
$3.38
70
O-Ring Mercedes-Benz
Mercedes-Benz Description: Separation point. 16.7x2.5. Engine Mounted A/C. 16.7 x 2.5mm. All Required. Roof Mounted A/C. 16.7 x 2.5mm. Refrigerant line to refrigerant line. 16.7x2.5. Suction line to compressor. 16.7x2.5. Refrigerant line connecting point. 16.7x2.5.
MSRP $17.00
$16.00
MSRP $17.00
$16.00
80
Valve Element Mercedes-Benz
Mercedes-Benz Description: Filling connection. Filler connection. High-pressure line. Filling valve. Suction line. Service connection, high pressure, air conditioning system. Valve element. To refrigerant line.
MSRP $19.50
$18.40
MSRP $19.50
$18.40
90
Screw Cap Mercedes-Benz
Mercedes-Benz Description: Filler connection. Filling connection. Low-pressure line. Seal. Suction line. Cover, service connection, low pressure, air conditioning system. Low-pressure side M8X1. To refrigerant line. Valve.
MSRP $12.00
$11.52
MSRP $12.00
$11.52
110
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: Rear lid to hinge lever. Drive to rear pillar. Pipe line to shock absorber leg reinforcement. Strut to front cross member. Bracket to car floor. Cooling pipe to front cross member. Engine hood upper catch to engine hood. Partition panel. Strut to stiffening,front central.
130
Refrigerant Line Mercedes-Benz
Mercedes-Benz Description: From separation point to separation point.
MSRP $120.00
$115.20
MSRP $120.00
$115.20
140
O-Ring Mercedes-Benz
Mercedes-Benz Description: Lower. Condenser and connecting point 3/8". Condenser to connecting point and expansion valve. Pressure line to expansion valve. Refrigerant line to expansion valve and connecting point. Refrigerant line to chiller. Refrigerant line to condenser, expansion valve and refrigerant line . Refrigerant line to shutoff valve. T0 refrigerant line. Refrigerant line to refrigerant line, expansion valve and evaporator.
MSRP $10.50
$10.08
MSRP $10.50
$10.08
170
Screw Cap Mercedes-Benz
Mercedes-Benz Description: Filler connection. High-pressure line. Cover, service connection, high pressure, air conditioning system. Filling connection m10x1. High-pressure side M10X1. To refrigerant line. Valve.
MSRP $6.75
$6.40
MSRP $6.75
$6.40
240
MSRP $2.50
$2.40
255
A/C Line O-Ring Mercedes-Benz
Mercedes-Benz Description: AT CONDENSER. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. PRESSURE LINE TO EXPANSION VALVE. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. Refrigerant li ...
260
O-Ring Mercedes-Benz
Mercedes-Benz Description: To evaporator. Line to condenser. Condenser and connecting point 1/2". Condenser to compressor. Pipe line to refrigerant compressor. Piping to refrigerant compressor. Between evaporator and expansion valve.
MSRP $8.75
$8.32
MSRP $8.75
$8.32
280
MSRP $145.00
$139.20
350
Condenser Mercedes-Benz
Mercedes-Benz Description: Compressor to condenser. Refrigerant. Heater/air conditioning. Sprinter van. 2.0l diesel. With heavy duty rear ac. 2.0l diesel.
360
Pressure Sensor Mercedes-Benz
Mercedes-Benz Description: Refrigerant line. Reservoir. Sprinter van. Refrigerant condenser. Refrigerant pressure sensor. Roof. Metris. Rear. At condenser,bottom m10.
MSRP $159.00
$152.00
MSRP $159.00
$152.00
370
Filter Dryer Mercedes-Benz
Mercedes-Benz Description: To condenser. Receiver drier parts kit. With heavy duty rear ac. 2.0l diesel.
MSRP $115.00
$110.40
MSRP $115.00
$110.40
